Product weight: 610kg
Assembled dimensions (LxWxH): 2450x2305x2620

Note: All feeders can accommodate two creep gates.
Creep gates are sold individually.


Weight: 610kg
Length: 2450mm
Width: 2305mm
Height Setting: Fill height Roof peak height
Dimensions at cattle height:
2420mm 2615mm
Flat-pack dimensions:
2440 x 1160 x 450 (LxWxH)
Feed Volume:
5500 litres
Feed weight – wheat/lupins:
Feed weight – barley/pellets:
Feed weight – oats:
Cattle or calves (paddock):
Cattle (feedlot):
  • Reinforced stainless steel troughs
  • Reinforced stainless steel upper adjusters
  • Reinforced stainless steel lower adjusters
  • 2x adjuster guards standard
  • Adjuster guard housing when not in use
  • High stability with hopper wholly over skids
  • 2x 65mm SHS braces between the skids
  • Hot gal dipped skids
  • Vertical brace in the centre of the skids
  • Laser cut corners in skids to prevent rust
  • Channel reinforced trough
  • Z275 sheet metal
  • 45 degrees angled trough
  • 100mm feed flow area
  • Rain protection reinforcing
  • Side wall bracing
  • Channel roof pivot bracket
  • 2x 200×100 RHS tine guides
  • Adjustable width tine guides
  • 6x adjuster braces
  • Dual tab adjuster braces
  • Viewing platform on opposing side of handle
  • Purchase flat-packed or assembled
  • User guide supplied
  • 4x locking bolts on the lower adjusters
  • Adjuster guard locking system
  • Dual positioned adjuster guard for dusty feeds
  • 8x 75mm round sight glasses
  • Vertical sidewall bracing for easy feed flow
  • 2x volume stickers
  • Cleaning tool supplied
  • Tube spanner supplied
  • Secure housing for tools
  • 2380mm trough length
  • Painted notch system on the adjusters
  • Drop lock pin roof locking system
  • Deep 110mm trough depth
  • Gutters on side walls drain out of feeder
  • Weather protection over the troughs
  • Reinforced roof edges
  • Mineral attachment option
  • Calf creep feeding gate option
  • Lamb creep feeding panel option
  • Rubber mat option
  • 2-year warranty
  • Trial reports available
