M3800HD
Flat Pack: £2940
Assembled: £3190
Stronger, Last Longer, More control
- Stainless Steel parts
- Precise 3 way saliva restriction system
- Load Sharing Suspension
- Tow empty at 100km/h
- 5 Year Extended Warranty*
- 30 Day Money Back Guarantee
| Weight: | 630kg |
|
Dimensions at sheep height :
|
3660x1650x1950 (LxWxH)
|
|
Dimensions at cattle height:
|
3660x1650x2150Â (LxWxH) |
| Flat-pack dimensions: | 2440x1160x450 (LxWxH) |
| Feed Volume: | 3800 litres |
| Feed weight – wheat/lupins: | 3000kg |
| Feed weight – barley/pellets: | 2400kg |
| Feed weight – oats: | 2000kg |
| Axle rating: | 3000kg |
| Spring Rating: | 3000kg |
| Tyre rating: | 3400kg |
| Tyre size: | 195/55R13C |
| Coupling rating: | 3500kg |
| Ewes or lambs (paddock): | 200-250 |
| Ewes or lambs (feedlot): |
120-150
|
| Ewes and lambs (creep feeding): |
 200-250 combined
|
| Cattle or calves (paddock): |
40-50
|
| Cattle (feedlot): | 30-35 |
| Goats (paddock): | 200-250 |
| Deer (paddock): | 120-150 |
| Pigs: | 120-150 |
- Reinforced stainless steel troughs
- Reinforced stainless steel upper adjusters
- Reinforced stainless steel lower adjusters
- 2x adjuster guards standard
- Adjuster guard housing when not in use
- 4x 40mm SHS stands
- High stability with hopper wholly over wheels
- Load sharing suspension
- Three axle height options
- Channel reinforced trough
- Z275 sheetmetal
- 45 degrees angled trough
- 100mm feed flow area
- Rain protection reinforcing
- Side wall bracing
- Channel roof pivot bracket
- 6x adjuster braces
- Dual tab adjuster braces
- 4x locking bolts on the lower adjusters
- Adjuster guard locking system
- Dual positioned adjuster guard for dusty feeds
- 8x 75mm round sight glasses
- Vertical side wall bracing for easy feed flow
- 2x volume stickers
- Adjuster feeder height in just 45 minutes
- Cleaning tool supplied
- Tube spanner supplied
- Secure housing for tools
- 4x new tyres
- Pivot up jockey wheel bracket
- Cast iron wheel on jockey wheel
- 2x safety chains supplied
- 2380mm trough length
- Painted notch system on the adjusters
- Drop lock pin roof locking system
- Deep 110mm trough depth
- Gutters on side walls drain out of feeder
- Weather protection over the troughs
- Reinforced roof edges
- Mineral attachment option
- Calf creep feeding gate option
- Lamb creep feeding panel option
- Rubber mat option
- 2-year warranty
- Standard operating procedure supplied
- User guide supplied
- Trial reports available
- Purchase flat-packed or assembled
